25mm Thickness Sheet Rolling Machine Hydraulich 4M / Min Rolling Speed

large.img.alt
small.img.alt

Large Image :  25mm Thickness Sheet Rolling Machine Hydraulich 4M / Min Rolling Speed

Product Details:
Place of Origin: China
Brand Name: SKSS
Certification: ISO / CE / CO
Model Number: W11S-25-2500
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiation
Packaging Details: Wooden Case
Delivery Time: 35 Days
Payment Terms: T/T, L/C, D/A
Supply Ability: 1 Sets Per Month
Detailed Product Description
Max Plate Thickness: 8 Mm Max Coil Width: 2000 Mm
Coil Speed: 5 M/min Motor Power: 7.5 KW
Top Roll Diameter: 280 Mm Roo Diameter: 440 Mm
High Light:

sheet rolling machine

,

Plate Bending Machine

25mm Thickness , 2500mm Width Hydraulich Plate Rolling Machine , 4M / Min Rolling Speed

Description

1. The machine is easily operated,easily maintained,with high rolling precision,it is an advanced,practical rolling device.
2. The lower roller is the main driving roller, and the upper roller can move vertically which is driven by hydraulic cylinders and horizontally.
3. It's displacement is controlled by computer, auto-leveling, screen display, and the synchronization inaccuracy is ± 0.2mm; horizontal movement adopts mechanical transmission.
4. The dumping and resetting of the flipping bearing is driven by hydraulic pressure, the ends of upper roller are equipped with balance systems, which can be used to unload the finished work piece.
5. This machine has an independent operating table to make operation convenient for workers and a safe connecting device, to ensure safety.





25mm Thickness Sheet Rolling Machine Hydraulich 4M / Min Rolling Speed 0



Specification



Detail Parameter

Upper working roller pressure

190T

Max rolling thickness

CS 25mm / SS 20mm symmetry rolling

CS 20mm / SS 15mm asymmetry rolling

Max rolling width

2500 mm

Max yield strength

σs≤245MPa

Plate rolling speed

4m/min

Main motor power

22 KW

Max spec. min bending diameter

Φ1100mm

Diameter of upper roller

Φ380mm

Diameter of lower roller

Φ220mm

Working roller surface length

2600mm

Center distance of lower roller

360mm

Equipment over size

5650X1940X2314mm

Self weight

18T



Main drive device


1. Main drive device is made up of electric motors,ZSY of decelerate of hard tooth flank,V-belt driving device, cylindrical gear transmission, and electro-hydraulic brakes. And the two lower rollers are driven by main reducer output gear drives to roll.
Upper rolls device
1. The upper roller device is consisted of upper roller oil cylinder,upper working roller,upper working roller bearing base and double row spherical roller bearing.Structure diagram is as picture here.
2. When upper roller cylinder drives lifts upper working rollers,two upper working rollers moves up and down along the guide rail of the machine frame,upper working roller amount is tested by grating ruler which is installed on the upper roller bearing base and machine frame,and make displacement amount be transferred into electricity signal by PLC and be showed by digital display device.PLC controls synchronization of upper working roller two ends,synchronization precision is ±0.2mm.





Competitive Advantage



1. The straightedge length can be set freely, the upper roller press to pre-bend.

2. Parameters are controlled by NC, easy for operation, improve the productivity greatly

3. The upper roller is like a drum, the lower rollers assorted with it through support rollers.

Bend continuously, can roll ideal products from thin to thick plates widely.

4. The lower rollers are fixed, the upper roller move vertically amd horizontally.

5. Complete structure, simple foundation, convenient move

The machine has unitary basement, does not need earth bolts, has simple foundation,

can move conveniently.





Package And Delivery



1. Seaway is the most common transportation way for oversea trading. Depends on your location, combined transport by rail and sea is also an option.

2. Certainly railway transportation is also acceptable if it is the most suitable approach.




Digital device



1. This machine adopts PLC programmable control system, grating ruler, digital display for upper roller vertical elevation, horizontal movement’s distance, it has simple and reliable manipulation .
2. Grating ruler is responsible for synchronical movement of two heads of upper roller, it gets feedback to PLC, while PLC automatically start and close motor direction valve to adjust elevation of two heads to get precise synchronical movement .
